CM8068403874521 Intel Intel Core i7-9700 Processor (12MB Cache, up to 4.7 GHz)









CM8068403874521 Intel Intel Core i7-9700 Processor (12MB Cache up to 4.7 GHz)

















Caratteristiche Commodity Classification Automated Tracking System (CCATS) G077159 CPU configuration (max) 1 Embedded options available No Execute Disable Bit Yes Export Control Classification Number (ECCN) 5A992C Idle States Yes Market segment Desktop Maximum number of PCI Express lanes 16 PCI Express CEM revision 3.0 PCI Express configurations 1x16/1x8+2x4/2x8 PCI Express slots version 3.0 Scalability 1S Supported instruction sets AVX 2.0/SSE4.1/SSE4.2 Thermal Monitoring Technologies Yes Thermal solution specification PCG 2015C Graphics Discrete graphics card No Discrete graphics card model Not available Maximum on-board graphics card memory 64 GB Number of displays supported (on-board graphics) 3 On-board graphics card Yes On-board graphics card 4K support Yes On-board graphics card base frequency 350 MHz On-board graphics card DirectX version 12.0 On-board graphics card dynamic frequency (max) 1200 MHz On-board graphics card maximum resolution (DisplayPort) 4096 x 2304 Pixels On-board graphics card maximum resolution (eDP - Integrated Flat Panel) 4096 x 2304 Pixels On-board graphics card maximum resolution (HDMI) 4096 x 2304 Pixels On-board graphics card model Intel? UHD Graphics 630 On-board graphics card OpenGL version 4.5 On-board graphics card refresh rate at maximum resolution (DisplayPort) 60 Hz On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) 60 Hz On-board graphics card refresh rate at maximum resolution (HDMI) 24 Hz Legal Information EU ECCN Code N/A UNSPSC Code (Icecat) 43201503 US ECCN Code 5A992 Logistics data Harmonized System (HS) code 8542310001 Memory ECC No Maximum internal memory supported by processor 128 GB Memory channels Dual-channel Memory clock speeds supported by processor 2666 MHz Memory types supported by processor DDR4-SDRAM Operational conditions Tjunction 100 ?C Other Caratteristiche Maximum internal memory 128 GB Package dimensions Depth (package,cm) 0,2 cm Gross Weight (Package kg) 0,035 kg Height (package,cm) 37,5 cm Width (package,cm) 37,5 cm Processor Box No Component for PC Cooler included No Generation 9th Generation Memory bandwidth supported by processor (max) 41,6 GB/s Processor ARK ID 191792 Processor base frequency 3 GHz Processor boost frequency 4,7 GHz Processor cache 12 MB Processor cache type Smart Cache Processor codename Coffee Lake Processor cores 8 Processor family Intel? Core? i7 Processor generation 9th gen Intel? Core? i7 Processor lithography 14 nm Processor manufacturer Intel Processor model i7-9700 Processor operating modes 64-bit Processor socket LGA 1151 (Socket H4) Processor threads 8 System bus rate 8 GT/s Thermal Design Power (TDP) 65 Watt Processor special Caratteristiche Enhanced Intel SpeedStep Technology Yes Intel 64 Yes Intel Clear Video Technology Yes Intel Software Guard Extensions (Intel SGX) Yes Intel Stable Image Platform Program (SIPP) Yes Intel Trusted Execution Technology Yes Intel TSX-NI Yes Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes Intel? AES New Instructions (Intel? AES-NI) Yes Intel? Boot Guard Yes Intel? Clear Video HD Technology (Intel? CVT HD) Yes Intel? Hyper Threading Technology (Intel? HT Technology) No Intel? Identity Protection Technology (Intel? IPT) Yes Intel? InTru? 3D Technology Yes Intel? Memory Protection Extensions (Intel? MPX) Yes Intel? Optane? Memory Ready Yes Intel? OS Guard Yes Intel? Quick Sync Video Technology Yes Intel? Secure Key Yes Intel? Transactional Synchronization Extensions Yes Intel? Turbo Boost Technology 2.0 Intel? Turbo Boost Technology 2.0 frequency 4,7 GHz Intel? vPro? Platform Eligibility Yes Product dimensions Net Weight (Product kg) 0,026 kg Product Depth 0,2 cm Product Height 37,5 cm Product Width 37,5 cm Technical details Bus speed 8 GT/s Launch date Q2'19 Maximum graphics card memory 64 GB Maximum memory 128 GB Maximum resolution & refresh rate (DisplayPort) 4096 x 2304@60Hz Processor ID 0x3E98 Product type Processor Status Launched Supported memory types DDR4-SDRAM ^ Brand Name Intel * 1 Anno(i) Weight & dimensions Processor package size 37.5 x 37.5 mm Categorie Categoria principale Parti per Server Computer e Stampanti Sottocategoria Server & Computer Sottocategoria Componenti di sistema Sottocategoria CPU
